Multi-Axis Accuracy from a Single Point
6-Axis Force/Torque Sensors
Low cross-axis interaction,
Temperature-compensated, and traceable calibration ;
6-DoF measurement.
Provides Fx-Fy-Fz and Mx-My-Mz data in a single body, synchronously and with low noise;
USB and MODBUS communication protocol options
Low-noise and high-precision digital 6-axis force and torque measurement
Inertial measurement unit for 6-axis acceleration and angular velocity measurement
Ideal mechanical interface connection for robotic grippers, compliant with ISO 9409-1:2004
Plug-and-Play
Internal signal conditioner
SIX-AXIS FORCE MOMENT SENSOR
Provides synchronous, low-noise Fx-Fy-Fz and Mx-My-Mz data in a single body; industrial connector, high sampling rate, and fast integration with MATLAB/Python/ROS SDK.
| Örnek Teknik Özellikler (6EKMA 1000) | ||||||
| Fx | Fy | Fz | Mx | My | Mz | |
| Ölçüm Aralığı (N) | 520 | 520 | 1000 | 16 | 16 | 12 |
| Aşırı Yük Limiti (N) | 832 | 832 | 1400 | 20 | 20 | 15 |
| Örnek Gürültü Değerleri (Yüksüz) (mN) | 9 | 9 | 17 | 6 | 4 | 6 |
| Boyut | 44 mm x Ø90 mm | |||||
| Kütle | 605 gr | |||||
| Çalışma Sıcaklığı | 4-55 (C) | |||||
| Seri Haberleşme | USB , MODBUS | |||||
| Maksimum Örnekleme Hızı | 400 Hz | |||||
| İvmeölçer | 3 eksen, maksimum ± 16 g | |||||
| Jiroskop | 3 eksen, maksimum ± 2000 o/sn | |||||
| Güç Kaynağı | 5V, 0.5 W | |||||
